| PIR Sensor Camera
|
|
|
|
| HTC-300N
NTSC |
|
| HTC-300P
PAL |
|
| HTC-300A
EIA |
|
| HTC-300C
CCIR |
|
| |

|
|
| |
|
| COLOR CAMERA SPECIFICATIONS |
| Description |
HMC-300N(NTSC) |
HMC-300P(PAL) |
| lmage sensor |
1/4 Inch CCD 270K pixel |
1/4 Inch CCD 310K pixel |
| Effective pixel |
H510 * V492 |
H512 * V582 |
| Scanning system |
525line 2:1 Interlacing |
625line 2:1 Interlacing |
| Sync. Ststem |
Intemal synchronizaion |
| Scanning frequency |
(H)15.734KHz * (V)59.94Hz |
(H)15.625KHz * (V)50Hz |
| Sub carrirer |
3.58 MHz |
4.43 MHz |
| Horizontal Resolution |
330 TV Lines above |
360 TV Lines above |
| Video output |
VBS 1.0Vp-p./75(Video:0.714Vp-p, Syn:0.286Vp-p) |
| S/N ratio |
48dB Min (AGC off, r=1, Y signal) |
| Gamma(r) |
r=0.45 |
| AGC |
+18dB Max |
| IRIS Electrical |
IRIS/Auto Iris |
| Standard Lux |
1,000 Lux at F 4.0(3,200'K) |
| Min.illumination |
0.5 Lux at F 1.4 AGC ON |
| Lens |
f=1.58mm F2.0 |
| Gain control |
Automatic gain control(0~18db) |
| White balance |
Automatic white balance control |
| Auto iris |
Electronic auto iris(Shutter speed:1/50,1/60~1/100.000) |
| Input voltage |
DC 12V ± 1V 160mA MAX |
| Ambient Temperature |
-10℃ ~ 60℃, 85%RH |
| Dimension |
50(W) X 45(H) X 47.5(D)mm |
| Housing Material |
Zinc & EGI |
| B/W CAMERA SPECIFICATIONS |
| Description |
HMC-300A(EIA) |
HMC-300C(CCIR) |
| lmage sensor |
1/3 Inch CCD 270K pixel |
1/3 Inch CCD 310K pixel |
| Effective pixel |
H510 * V492 |
H512 * V582 |
| Scanning system |
525line 2:1 Interlacing |
625line 2:1 Interlacing |
| Sync. Ststem |
Intemal synchronizaion |
| Scanning frequency |
(H)15.734KHz * (V)59.94Hz |
(H)15.625KHz * (V)50Hz |
| Sub carrirer |
3.58 MHz |
4.43 MHz |
| Horizontal Resolution |
360 TV Lines above |
380 TV Lines above |
| Video output |
1.0Vp-p.75ohm Synchronous negative polarity |
| S/N ratio |
50dB above(when agc off) |
| Gamma(r) |
r=0.45 |
| AGC |
+18dB Max |
| IRIS Electrical |
IRIS/Auto Iris |
| Shutter speed |
1/60~1/100,000 sec 1/50~1/100,000 sec |
| Standard Lux |
1,000 Lux F 4.0(3,200'K) |
| Min.illumination |
0.1 Lux 1.4(0.5Lux F 1.8) |
| Lens |
f=2.5mm F2.0 |
| Gain control |
Automatic adjustment by auto-iris controller |
| Input voltage |
DC 12V ± 1V 120mA MAX |
| Ambient Temperature |
-10℃ ~ 60℃, 85%RH |
| Dimension |
50(W) X 45(H) X 47.5(D)mm |
| Housing Material |
Zinc & EGI |
|
|
 |
